Catalyst 2960-S

Device Type Switch – 24 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 24 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) Yes
Performance
Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 65.5 MppsRAM: 128 MB
Flash Memory :64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T – RJ-45 – PoE
Voltage Required :AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 55 Watt
Width :17.5 in. (44.5 cm)
Depth: 15.2 in. (38.6 cm)
Height :1.8 in. (4.5 cm)
Weight: 13 lbs (5.77 kg)
Rack Mounting Kit Optional
MTBF :237,016 hour(s)

Device Type Switch – 48 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 48 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) Yes
Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 101.2 Mpps

MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH
Encryption Algorithm SSL
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
RAM :  128 MB
Flash Memory : 64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 48 x 10Base-T/100Base-TX/1000Base-T – RJ-45
USB : 1 x 4 PIN USB Type A
1 x console – mini-USB Type B – management
1 x console – RJ-45 – management
1 x 10Base-T/100Base-TX – RJ-45 – management
2 x SFP+
Expansion Slot(s) 1 (total) / 1 (free) x Stacking Module
Power
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 55 Watt
Width 17.5 in. (44.5 cm)
Depth 11.8 in. (29.9 cm)
Height 1.8 in. (4.5 cm)
Weight 9.5 lbs (4.3 kg)
Rack Mounting Kit Optional
MTBF 311,291 hour(s)

Device Type  : Switch – 24 ports – Managed
Enclosure Type :  Rack-mountable – 1U
Ports : 24 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) :  Yes
Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 65.5 Mpps

MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH
Encryption Algorithm SSL
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
RAM 128 MB
Flash Memory 64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T – RJ-45
USB : 1 x 4 PIN USB Type A
1 x console – mini-USB Type B – management
1 x console – RJ-45 – management
1 x 10Base-T/100Base-TX – RJ-45 – management
2 x SFP+
Expansion Slot(s) 1 (total) / 1 (free) x Stacking Module
Power
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational : 39 Watt
Width : 17.5 in. (44.5 cm)
Depth :  11.8 in. (29.9 cm)
Height :  1.8 in. (4.5 cm)
Weight : 9.5 lbs (4.3 kg)
Rack Mounting Kit Optional
MTBF :  332,958 hour(s)
Software Included Cisco IOS LAN Base
Min Operating Temperature :23 °F (-5 °C)
Max Operating Temperature :104 °F (40 °C)
Humidity Range Operating :10 – 95% (non-condensing)
Min Storage Temperature :-13 °F (-25 °C)
Max Storage Temperature :158 °F (70 °C)
Humidity Range Storage: 10 – 95% (non-condensing

Device Type Switch – 24 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 24 x 10/100/1000 + 4 x SFP
Power Over Ethernet (PoE) PoE
Performance Switching capacity : 176 Gbps ¦ Forwarding performance (64-byte packet size) : 41.7 Mpps
MAC Address Table Size 8K entries
Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH
Encryption Algorithm: SSL
Authentication Method: Secure Shell (SSH), RADIUS, TACACS+
RAM: 128 MB
Flash Memory:64 MB Flash
Status Indicators:Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T – RJ-45 – PoE ¦ USB : 1 x 4 PIN USB Type A ¦ 1 x console – mini-USB Type B – management ¦ 1 x console – RJ-45 – management ¦ 1 x 10Base-T/100Base-TX – RJ-45 – management ¦ 4 x SFP (mini-GBIC)
Expansion Slot(s) 1 (total) / 1 (free) x Stacking Module
Power
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 55 Watt
Width 44.5 cm
Depth 38.6 cm
Height 4.5 cm
Weight 5.77 kg
Rack Mounting Kit Optional
MTBF 245,604 hour(s)

Switch Model:Catalyst 2960-S Switches

Description : with 1 Gigabit Uplinks and 10/100/1000

Uplinks : Ethernet Connectivity

Manufacturer: Cisco
Product ID: WS-C2960S-24TS-L
Product Description: Cisco CAT2960S Stack 24 Gige-4 x SFP LAN Base
Product Type: Ethernet Switch
Number of Ports: 24
Gigabit Ethernet Port: Yes
Interfaces/Ports: 24 x RJ-45 10/100/1000Base-T Network LAN
Forwarding/Filtering Rate: 41.7 Mpps
Switching Throughput: 176 Gbps
Number of Expansion Slots: 5
Expansion Slots: (4 Total) SFP (mini-GBIC) Uplink
(1 Total) Stacking Module
Layer Support: 2
Standard Memory: 128MB
Memory Technology: DRAM
Flash Memory: 64MB
Input Voltage: 110 V AC
220 V AC
Input Voltage Range: 100 V AC to 240 V AC
Power Source: Power Supply
Redundant Power Supply: Yes
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Dimensions: 1.75″ Height x 17.50″ Width x 11.80″ Depth
Weight (Approximate): 10 lb
