Switch et Accessoires Cisco

Device Type Switch – 48 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 48 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) Yes
Performance Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 101.2 Mpps
RAM :128 MB
Flash Memory: 64 MB Flash
Power Device Power supply – internal
Voltage Required :AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 81 Watt
Width :17.5 in
Depth :15.2 in
Height :1.8 in
Weight: 13 lbs
Rack Mounting Kit Optional
MTBF: 183,498 hour(s)

Device Type Switch – 24 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 24 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) Yes
Performance
Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 65.5 MppsRAM: 128 MB
Flash Memory :64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T – RJ-45 – PoE
Voltage Required :AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 55 Watt
Width :17.5 in. (44.5 cm)
Depth: 15.2 in. (38.6 cm)
Height :1.8 in. (4.5 cm)
Weight: 13 lbs (5.77 kg)
Rack Mounting Kit Optional
MTBF :237,016 hour(s)

Device Type Switch – 48 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 48 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) Yes
Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 101.2 Mpps

MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH
Encryption Algorithm SSL
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
RAM :  128 MB
Flash Memory : 64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 48 x 10Base-T/100Base-TX/1000Base-T – RJ-45
USB : 1 x 4 PIN USB Type A
1 x console – mini-USB Type B – management
1 x console – RJ-45 – management
1 x 10Base-T/100Base-TX – RJ-45 – management
2 x SFP+
Expansion Slot(s) 1 (total) / 1 (free) x Stacking Module
Power
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 55 Watt
Width 17.5 in. (44.5 cm)
Depth 11.8 in. (29.9 cm)
Height 1.8 in. (4.5 cm)
Weight 9.5 lbs (4.3 kg)
Rack Mounting Kit Optional
MTBF 311,291 hour(s)

Manufacturer Cisco
Product ID: WS-C2960S-48LPS-L
Product Description: Cisco CAT2960S Stack 48 Gige-POE 370W 4 x SFP LAN
Product Type: Ethernet Switch
Number of Ports: 48
Gigabit Ethernet Port: Yes
Interfaces/Ports: 48 x RJ-45 10/100/1000Base-T PoE LAN
Forwarding/Filtering Rate: 77.4 Mpps
Switching Throughput: 176 Gbps
Number of Expansion Slots: 5
Expansion Slots: (4 Total) SFP (mini-GBIC) Uplink
(1 Total) Stacking Module
Layer Support: 2
Manageable: Yes
Management:
IEEE 802.1p QoS
DHCP
IEEE 802.1Q VLAN
RMON
CLI
CiscoWorks LAN Management Solution
SNMPv3
Syslog
Standard Memory: 128MB
Memory Technology: DRAM
Flash Memory: 64MB
Operating System: Cisco IOS
Power Description
Power Over Ethernet: Yes
Power Source: Power Supply
Redundant Power Supply: Yes
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Stackable
Dimensions: 1.75″ Height x 17.50″ Width x 15.20″ Depth
Weight (Approximate): 12.50 lb

Device Type Switch – 24 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports 24 x 10/100/1000 + 4 x SFP
Power Over Ethernet (PoE) PoE
Performance Switching capacity : 176 Gbps ¦ Forwarding performance (64-byte packet size) : 41.7 Mpps
MAC Address Table Size 8K entries
Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH
Encryption Algorithm: SSL
Authentication Method: Secure Shell (SSH), RADIUS, TACACS+
RAM: 128 MB
Flash Memory:64 MB Flash
Status Indicators:Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 24 x 10Base-T/100Base-TX/1000Base-T – RJ-45 – PoE ¦ USB : 1 x 4 PIN USB Type A ¦ 1 x console – mini-USB Type B – management ¦ 1 x console – RJ-45 – management ¦ 1 x 10Base-T/100Base-TX – RJ-45 – management ¦ 4 x SFP (mini-GBIC)
Expansion Slot(s) 1 (total) / 1 (free) x Stacking Module
Power
Power Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 55 Watt
Width 44.5 cm
Depth 38.6 cm
Height 4.5 cm
Weight 5.77 kg
Rack Mounting Kit Optional
MTBF 245,604 hour(s)

Switch Model:Catalyst 2960-S Switches

Description : with 1 Gigabit Uplinks and 10/100/1000

Uplinks : Ethernet Connectivity

Manufacturer  : Cisco
Product ID: WS-C2960S-48TS-L
Product Description: Cisco CAT2960S Stack 48 Gige-4 x SFP LAN Base
Product Type: Ethernet Switch
Number of Ports: 48
Gigabit Ethernet Port: Yes
Interfaces/Ports: 48 x RJ-45 10/100/1000Base-T Network LAN
Forwarding/Filtering Rate: 77.4 Mpps
Switching Throughput: 176 Gbps
Number of Expansion Slots: 4
Expansion Slots: (4 Total) SFP (mini-GBIC)
Layer Support: 2
Manageable: Yes
Management: IEEE 802.1p QoS , DHCP , IEEE 802.1Q VLAN , RMON , CLI ,CiscoWorks LAN Management Solution , SNMPv3 , Syslog
Standard Memory: 128MB
Memory Technology: DRAM
Flash Memory: 64MB
Operating System: Cisco IOS
Power Source: Power Supply
Redundant Power Supply: Yes
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Dimensions: 1.75″ Height x 17.50″ Width x 11.80″ Depth
Weight (Approximate): 10.50 lb
