WS-C2960-48PST-L-M

Type Fixed
Topology Ethernet (10/100BaseTX)
Maximum Port density 24 10/100 ports
Uplinks n/a
Modular/Expansion Slots n/a
Architecture Layer 2 Switching (basic connectivity), Voice Enabled
Form Factor Fixed, Rack Mountable, Standalone/Clustering
Dimensions 1.73 x 17.5 x 9.3 in.
DRAM 64 MB
Throughput 3.6 Mpps
Backplane Capacity 16 Gbps
Number of VLANs 64

Device Type Switch – 48 ports – Managed
Enclosure Type Rack-mountable – 1U
Ports :48 x 10/100/1000 + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE) Yes
Performance Switching capacity : 176 Gbps
Forwarding performance (64-byte packet size) : 101.2 Mpps
RAM: 128 MB
Flash Memory 64 MB Flash
Status Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Interfaces 48 x 10Base-T/100Base-TX/1000Base-T – RJ-45 – PoE
USB : 1 x 4 pin USB Type A
1 x console – mini-USB Type B – management
1 x console – RJ-45 – management
1 x 10Base-T/100Base-TX – RJ-45 – management
2 x SFP+
Expansion Slot(s) 1 (total) / 1 (free) x Stacking ModulePower Device Power supply – internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 71 Watt
Voltage Required: AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 71 Watt

Min Operating Temperature: 23 °F (-5 °C)
Max Operating Temperature: 104 °F (40 °C)
Humidity Range Operating: 10 – 95% (non-condensing)
Min Storage Temperature: -13 °F (-25 °C)
Max Storage Temperature: 158 °F (70 °C)
Humidity Range Storage: 10 – 95% (non-condensing)
